H400-450XD
BIG TRUCKS FOR HEAVY-DUTY APPLICATIONS
Depend on the power of Hyster® heavy-duty forklifts
- Robust design
- Excellent visibility
- Low cost of ownership
- Operator comfort
- Easily serviceable
Features
- The mast, with robust mast channels, rollers, stub shafts and chain anchors, is designed to excel in heavy duty applications. The sturdy mast design for this truck series enables less mast deflections while offering a number of 2-stage mast options for a wide variety of applications in multiple industries.
- Greaseable load rollers with roller bearings can provide years of dependable performance in the front end. Carriages are designed to have minimal capacity derate on sideshifting carriages, enabling the truck to provide close to full rated capacity under all operating conditions.
- Available in short wheel base to deliver an optimum combination of compactness, nimbleness and agility for applications with space constraints requiring a tighter turning radius.
- A low profile carriage enables a clear line of vision for an optimized view of fork tips. Forward visibility is uncluttered by the position of hydraulic valves, hoses or mast crossmembers with a clear view through the mast window. Canted hoses are arranged along the line of sight so the operator sees only one hose and has good visibility.
- Curved, scratch resistant, tempered glass front and rear windshields, armored glass top window and steel-framed glass doors provide operators with excellent all-around visibility. On the exterior, sloping counterweights enhance visibility of steer tires for improved maneuverability and reduced tire gouging.
- The engine design produces more power and torque using XPI high-pressure, common-rail fuel injection and variable geometry turbochargers. Advanced controls enable the engine to provide peak performance and operating efficiency while delivering great fuel economy and durability.
Specifications
- Max Weight: 45,000 lbs
- Capacity: 40000-45000 lbs
- Max Height: 275
- Type: HIGH CAPACITY INTERNAL COMBUSTION TRUCKS PNEUMATIC TIRE
- Series Title: H400-450XD
| Model | Load Capacity | Load Center | Lift Height | Turning Radius | Overall Width | Weight | Engine Type | Transmission |
|---|---|---|---|---|---|---|---|---|
| H400XD | 40000lbs | 48in | 275 | 194 | 115 | 61963 | Cummins QSB 6.7L Diesel | ZF – 5WG211 |
| H450XDS | 45000lbs | 36in | 275 | 207 | 115 | 66416 | Cummins QSB 6.7L Diesel | ZF – 5WG211 |
| H400XDS | 40000lbs | 36in | 275 | 194 | 2923 | 28106 | Cummins QSB 6.7L Diesel | ZF – 5WG211 |
| H450XD | 45000lbs | 48in | 275 | 207 | 115 | 63833 | Cummins QSB 6.7L Diesel | ZF – 5WG211 |
Other High Capacity Models
