H40-70A
Internal Combustion
DISTINCTLY HYSTER, BUILT FOR YOU
Start with a singular base configuration, then add only what you need to best suit your operational needs — no more, no less. By designing a completely unique forklift, you get the comfort and performance you desire, plus the cost benefit of only paying for what your operators and operation need in order to perform optimally.
Specifications
- Max Weight: 7,000 lbs
- Capacity: 4000-7000 lbs
- Max Height: 200
- Type: ICE PNEUMATIC TIRE
- Series Title: H40-70A
THE RIGHT EQUIPMENT FOR YOUR APPLICATION.
Features
- Dynamic Stability System (DSS)
- Keep Costs Under Control
- Operator-Centric Design
- Exceptional Visibility
- Operator Assistance Systems
| Model | Load Capacity | Load Center | Lift Height | Turning Radius | Overall Width | Weight | Engine Type | Transmission |
|---|---|---|---|---|---|---|---|---|
| H70A | 7000lbs | 24in | 200 | 96.4 | 46.7 / 53.3 | 10680 | Yanmar 2.1L Diesel / Yanmar 2.2L LPG | Powershift 1-speed / Duramatch |
| H40A | 4000lbs | 24in | 200 | 86.3 | 45.7 / 50.4 | 7600 | Yanmar 2.1L Diesel / Yanmar 2.2L LPG | Powershift 1-speed / Duramatch |
| H60A | 6000lbs | 24in | 200 | 93.5 | 46.7 / 53.3 | 9890 | Yanmar 2.1L Diesel / Yanmar 2.2L LPG | Powershift 1-speed / Duramatch |
| H50A | 5000lbs | 24in | 200 | 89.1 | 45.7 / 50.4 | 8430 | Yanmar 2.1L Diesel / Yanmar 2.2L LPG | Powershift 1-speed / Duramatch |
